| Grade | C | Mn | Si | S | P | Cr | Mo |
| ASTM A234 WP5 Fittings | ≤0.15 | ≤0.6 | ≤0.5 | ≤0.04 | ≤0.03 | 4-6 | 0.44-0.65 |
| Standard Specification : | ASTM A234 WP5 Fittings |
| Coating Fitting Faces : | Anti-rust Paint, Cold and Hot Dip Galvanized, Yellow Transparent, Oil Black Paint, Zinc Plated |
| Fitting Machining Equipment: | Sand-blasting machine, Press machine, Bending machine, Pushing Machine, electric bevelling machine etc |
| Rating Pressure: | Pressure Rating Of: 3000 LBS, 6000 LBS, 9000 LBS |
| Thickness: | View Our Thickness: Schedule 5S, SCH10, SCH20, SCH10, SCH20, SCH30, SCHTD, SCH40, SCH60, XS, SCH80, SCH100, SCH120, SCH140, SCH160. |
| Standard: | MSS-SP-43 Type b Fittings, MSS-SP-43 Type B Fittings, ANSI B16.28 Fittings, JIS B2313 Fittings, ANSI B16.9 Fittings, MSS-SP-43 Type A Fittings, JIS B2312 Fittings |
| Dimensions Class: | 2000#, 3000#, 6000#, 9000# |
| Check Sizes: | (SMLS UPTO 24”) 1/2” TO 36” (Buttweld 8” TO 36” ) |
| Application: | Fabrication Industry Chemical Industry Nuclear Power Plant Natural Gas Industry Water Pipeline Industry Oil And Gas Industry |
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| SA234 WP5 Fitiings | 415 - 585 | ≥205 | ≥20 |
ASTM A234 Grade WP5 Reducing Tee
Alloy Steel ASTM A234 WP5 Lateral Tee
Alloy ASTM A234 WP5 Cl1 Equal Cross
ASTM ASTM A234 WP5 Welded Stub End
ASME A234 Grade WP5 End Cap
Alloy Steel Grade WP5 Short Radius Elbow
Alloy Steel a234 WP5 LR Elbow
ASI B16.9 Alloy Steel WP5 Eccentric Reducer
Alloy Steel SA234 Gr WP5 Concentric Reducer
ASTM A234 Grade WP5 Equal Tee
ASTM Alloy Steel Grade WP5 45 Degree Elbow
ASME B16.9 A234 Grade WP5 90 Degree Elbow
