BS EN 10241 Wrought Iron Pipe Fitting And Wrought Flange Manufacturer In India

  • Home
  • Wrought Iron Fittings
ASME B16.9 Wrought Iron Fittings
ASME B16.9 Wrought Iron Fittings
ANSI B16.5 Wrought Iron Flange
ANSI B16.5 Wrought Iron Flange
BS En 10241 Wrought Iron Pipe Fittings
BS En 10241 Wrought Iron Pipe Fittings

Wrought Iron Flange Dimension


CLASS NPS Wrought Iron SORF Flanges Wrought Iron NPT Flanges Wrought Iron SW Flanges Wrought Iron Loose Flanges Wrought Iron BLRF Flanges Wrought Iron WN Flanges
150# ½ 1 1 2 1 2 2
¾ 2 2 2 2 2 2
1 2 2 2 2 2 3
1¼ 3 3 3 3 3 3
1½ 3 3 3 3 4 4
2 5 5 5 5 5 6
2½ 8 8 8 8 7 10
3 9 9 9 9 9 11.5
3½ 11 12 11 11 13 12
4 13 13 13 13 17 16.5
5 15 15 15 15 20 21
6 19 19 19 19 27 26
8 30 30 30 30 47 42
10 43 43 43 43 70 54
12 64 64 64 64 123 88
14 90 90 90 105 140 114
16 106 98 98 140 180 140
18 130 130 130 160 220 165
20 165 165 165 195 285 197
22 185 185 185 245 355 225
24 220 220 220 275 430 268
CLASS NPS SORF NPT Flanges SW Loose BLRF WN
300# ½ 2 2 3 2 2 2
¾ 3 3 3 3 3 3
1 3 3 3 3 4 4
1¼ 4.5 4.5 4 4.5 6 5
1½ 6.5 6.5 6 6.5 7 7
2 7 7 7 7 8 9
2½ 10 10 10 10 12 12
3 13 14 13 14.5 16 18
3½ 17 17 17 17 21 20
4 23.5 24 22 24 28 26.5
5 29 31 28 28 37 36
6 39 39 39 39 50 45
8 58 58 58 58 81 69
10 81 81 81 91 124 100
12 115 115 115 140 185 142
14 165 165 165 190 250 206
16 210 220 190 234 315 250
18 253 280 250 305 414 320
20 315 325 315 375 515 400
22 370 370 370 435 640 465
24 490 490 475 550 800 580
CLASS NPS SORF NPT Flanges SW Loose BLRF WN
600# ½ 2 2 2 2 3 3
¾ 3 3 3 3 4 4
1 4 4 4 4 4 4
1¼ 5 5 5 5 6 6
1½ 7 7 7 7 8 8
2 9 9 9 9 10 12
2½ 13 13 13 12 15 18
3 16 16 16 15 20 23
3½ 21 21 21 20 29 26
4 37 37 37 36 41 42
5 63 63 63 63 68 68
6 80 80 80 78 86 81
8 115 15 15 112 140 120
10 177 177 177 195 231 190
12 215 215 215 240 295 226
14 259 259 259 290 378 347
16 366 366 366 400 527 481
18 476 476 476 469 665 555
20 612 612 612 604 855 690
22 590 590 590 670 1000 720
24 876 876 876 866 1250 977

BS En 10241 Wrought Iron Pipe Fittings Weight


BS En 10241 Wrought Iron Pipe Fittings Weight Chart


Wrought Iron Blind Flanges Specification


Specification : Wrought Iron Fittings
Supporting Flange Material: Gasket, Flange Bolts, Ring Joint
Application: Natural Gas Industry
Oil And Gas Industry
Chemical Industry
Water Pipeline Industry
Nuclear Power Plant
Fabrication Industry
Design For Size: ASME Fittings, BS Fittings, DIN Fittings, EN Fittings, ASA Fittings, JIS Fittings, ANSI Fittings, PN Fittings
Flange Machining Equipment: Sand-blasting machine, Pushing Machine, Press machine, Bending machine, electric bevelling machine etc
Connect Type: LJF, RF, FF, LMF, SMF, RTJ
Size Chart : 1/2″ (15 NB) To 48″ (1200NB)
Production Process: Machined, Forged, Heat Treated
Coating Flange Faces : Anti-rust Paint, Cold and Hot Dip Galvanized, Zinc Plated, Yellow Transparent, Oil Black Paint
Standards: ASME B16.38 Flange, EN-1092 Flange, BS10 Flange, DIN Flange, PN Flange, JIS Flange, GOST Flange, UNI Flange, AWWA Flange, MSS SP44 Flange, ASME B16.5 Flange, ISO Flange, ASME B16.47 (Series A, Series B)
Pressure Rating Table: Class 150 LBS Fittings, Class 300 LBS Fittings, Class 600 LBS Fittings, Class 900 LBS Fittings, Class 1500 LBS Fittings, Class 2500 LBS Fittings
Common Types of Flange : Flanges 150 LB WNRF
Class 300 RTJ
600# BLRF
Class 900 SORF

Type Of Wrought Iron Threaded Fittings And Fittings


Wrought Iron Piping

Wrought Irons Piping

Wrought Iron Gate Fittings

Wrought Irons Gate Fittings

Wrought Iron Pipe Fittings

Wrought Irons Pipe Fittings

Wrought Iron Light Fittings

Wrought Irons Light Fittings

Wrought Iron Window Fittings

Wrought Irons Window Fittings

Wrought Iron Door Fittings

Wrought Iron Door Fittings

Wrought Iron Flanges

Wrought Irons Flanges

Wrought Iron Railing Flange

Wrought Irons Railing Flanges

Wrought Iron Floor Flange

Wrought Irons Floor Flanges

Wrought Iron Post Flange

Wrought Irons Post Flanges


Wrought Iron Railing Flange Pressure Rating


ASME Wrought Iron Fittings Pressure Rating
Temperature °F Class 150 Class 300 Class 400 Class 600 Class 900 Class 1500 Class 2500
-20 to 100 275 720 960 1440 2160 3600 6000
200 230 600 800 1200 1800 3000 5000
300 205 540 720 1080 1620 2700 4500
400 190 495 660 995 1490 2485 4140
500 170 465 620 930 1395 2330 3880
600 140 435 580 875 1310 2185 3640
650 125 430 575 860 1290 2150 3580
700 110 425 565 850 1275 2125 3540
750 95 415 555 830 1245 2075 3460
800 80 405 540 805 1210 2015 3360
850 65 395 530 790 1190 1980 3300
900 50 390 520 780 1165 1945 3240
950 35 380 510 765 1145 1910 3180
1000 20 320 430 640 965 1605 2675
1050 20 310 410 615 925 1545 2570
1100 20 255 345 515 770 1285 2145
1150 20 200 265 400 595 995 1655
1200 20 155 205 310 465 770 1285
1250 20 115 150 225 340 565 945
1300 20 85 115 170 255 430 715
1350 20 60 80 125 185 310 515
1400 20 50 65 95 145 240 400
1450 15 35 45 70 105 170 285
1500 10 25 35 55 80 135 230
