| Specification : | ASTM A182 F22 Flange |
| Design For Size: | JIS Flange, EN Flange, ASA Flange, ANSI Flange, BS Flange, PN Flange, ASME Flange, DIN Flange |
| Pressure: | Check Pressure Rating Of Socket, Threaded: 3000 LBS, 6000 LBS, 9000 LBS |
| Dimensions Class: | 2000# Fittings, 3000# Fittings, 6000# Fittings, 9000# Fittings |
| Forged Type : | NPT (Threaded) Fittings, BSPT Fittings, BSPP Fittings. |
| Standards: | BS10 Flange, DIN Flange, PN Flange, JIS Flange, ISO Flange, GOST Flange, UNI Flange, AWWA Flange, MSS SP44 Flange, ASME B16.38 Flange, EN-1092 Flange, ASME B16.5 Flange, ASME B16.47 (Series A, Series B) Flange |
| Size Chart : | 1/2″ (15 NB) To 48″ (1200NB) |
| Common Types of Flange : | Flanges 150 LB WNRF Class 300 RTJ 600# BLRF Class 900 SORF |
| Flange Machining Equipment: | Electric bevelling machine, Sand-blasting machine, Bending machine, Pushing Machine, Press machine etc |
| Production Process: | Forged, Heat Treated, Machined |
| Coating Flange Faces : | Oil Black Paint, Yellow Transparent, Anti-rust Paint, Zinc Plated, Cold and Hot Dip Galvanized |
| Connect Type Type: | RF Flange, FF Flange, RTJ Flange, LMF Flange, SMF Flange, LJF Flange |
| Application: | Fabrication Industry Water Pipeline Industry Nuclear Power Plant Chemical Industry Oil And Gas Industry Natural Gas Industry |
| Dimension Standards | Size Range | Ratings |
|---|---|---|
| ASTM A182 F22 Socket Weld Flanges | 1/2" to 24" | 150# to 2500# |
| Alloy Steel A182 F22 Lapped joint Flanges | 1" TO 24" | 300# TO 2500# |
| SA182 Gr F22 Alloy steel flange | 26" TO 48" | 150# TO 600# |
| Chromoly F22 Alloy steel lap joint flange | 12" TO 60" | 150# to 900# |
| Low Alloy Steel ASTM A182 F22 WNRF Flanges | 26" TO 60" | -- |
| SA182 F22 Alloy Steel RTJ Flange | 2 1/6" TO 30" | 2000 PSI TO 20000 PSI |
| A182 Gr F22 Flat Flange | 1/2" TO 24" | 150# TO 2500# |
| Alloy Steel F22 Slip On Flanges | DN10 TO DN3600 | PN6 TO PN160 |
Alloy Steel F22 Reducing Flange
Alloy Steel A182 F22 Weld Neck Flange
Alloy A182 Gr F22 Blind Flange
Steel ASTM A182 Grade F22 Flat Face Flange
Alloy Steel F22 Forged 90 Degree Elbow
Alloy Steel A182 F22 Socket Weld Cap
Alloy SA182 F22 Forged 45 Degree Elbow
ASTM A182 Gr F22 SW Full Coupling
Alloy Steel SA 182 Gr F22 Steel RTJ Flange
Alloy Steel A182 Grade F22 Raised Face Flange
AS A182 F22 Socket Weld Flange
Alloy Steel A182 F22 Alloy Steel Slip On Flange
| Grade | C | Mn | Si | S | P | Cr | Mo |
| ASTM A182 F22 Flange | 0.05 - 0.15 | 0.3 - 0.6 | 0.5 | 0.03 | 0.045 | 0.8 - 1.25 | 0.044 - 0.65 |
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| SA 182 Gr F22 | 205 | 415 | 20 |
| Material Group | Common Name | Type | UNS | Forging Spec. | Casting Spec. Equivalent | DIN |
|---|---|---|---|---|---|---|
| 2.1/4Cr-1Mo | K21590 | ASTM A182-F22 cl3 | SA217-WC9 | 10CRM0910 | 1.7380 | Up to 593ºC (1100ºF), HP steam |
| ANSI/ASME B16.34 | ANSI PRESSURE RATING | ||||||
| Temperature °F | 150 LB | 300 LB | 400 LB | 600 LB | 900 LB | 1500 LB | 2500 LB |
| -20 to 100 | 265 | 695 | 925 | 1390 | 2085 | 3470 | 5785 |
| 200 | 260 | 680 | 905 | 1360 | 2035 | 3395 | 5660 |
| 300 | 230 | 655 | 870 | 1305 | 1955 | 3260 | 5435 |
| 400 | 200 | 640 | 855 | 1280 | 1920 | 3200 | 5330 |
| 500 | 170 | 620 | 830 | 1245 | 1865 | 3105 | 5180 |
| 600 | 140 | 605 | 805 | 1210 | 1815 | 3025 | 5040 |
| 650 | 125 | 590 | 785 | 1175 | 1765 | 2940 | 4905 |
| 700 | 110 | 570 | 755 | 1135 | 1705 | 2840 | 4730 |
| 750 | 95 | 530 | 710 | 1065 | 1595 | 2660 | 4430 |
| 800 | 80 | 510 | 675 | 1015 | 1525 | 2540 | 4230 |
| 850 | 65 | 485 | 650 | 975 | 1460 | 2435 | 4060 |
| 900 | 50 | 450 | 600 | 900 | 1350 | 2245 | 3745 |
| 950 | 35 | 280 | 375 | 560 | 845 | 1405 | 2345 |
| 1000 | 20 | 165 | 220 | 330 | 495 | 825 | 1370 |
