| Specification : | ASME B16.47 Flange |
| Connect Type Type: | LJF, LMF, SMF, RF, FF, RTJ. |
| ASA Flanges Size Chart : | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces : | Zinc Plated, Oil Black Paint, Anti-rust Paint, Yellow Transparent, Cold and Hot Dip Galvanized |
| Application: | Fabrication Industry Oil And Gas Industry Natural Gas Industry Water Pipeline Industry Nuclear Power Plant Chemical Industry |
| ASME B16.47 Flange Standards : | BS10, JIS, MSS SP44, EN-1092, ASME B16.47 (Series A, Series B), PN, ISO, ASME B16.38, AWWA, DIN, GOST, UNI, ASME B16.5. |
| Design For Size: | ASME, EN, DIN, ASA, PN, JIS, ANSI, BS |
| Machining Equipment: | Pushing Machine, Bending machine, Electric bevelling machine, Press machine, Sand-blasting machine etc |
| Production Process: | Forged, Heat Treated and Machined |
| Pressure Rating Table: | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Normal Pipe Size | Dimensions | Weight (Kilogram) | ||||
|---|---|---|---|---|---|---|
| NPS (In.) |
DN (millimeter) | FLANGES Outer Diameter Millimeter Millimeter |
FLANGES Thickness D millimeter |
SOW Socket Weld |
Weld Neck | Blind |
| 1/2 | 15 | 88.9 | 11.2 | 0.4 | 0.5 | 0.4 |
| 3/4 | 20 | 98.6 | 12.7 | 0.6 | 0.7 | 0.6 |
| 1 | 25 | 108 | 14.2 | 0.8 | 1 | 0.9 |
| 1 1/4 | 32 | 117.3 | 15.7 | 1 | 1.3 | 1.2 |
| 1 1/2 | 40 | 127 | 17.5 | 1.3 | 1.7 | 1.5 |
| 2 | 50 | 152.4 | 19.1 | 2.1 | 2.6 | 2.4 |
| 2 1/2 | 65 | 177.8 | 22.4 | 3.3 | 4.1 | 3.9 |
| 3 | 80 | 190.5 | 23.9 | 3.9 | 4.9 | 4.9 |
| 3 1/2 | 90 | 215.9 | 23.9 | 4.8 | 6.1 | 6.2 |
| 4 | 100 | 228.6 | 23.9 | 5.3 | 6.8 | 7.0 |
| 5 | 125 | 254 | 23.9 | 6.1 | 8.6 | 8.6 |
| 6 | 150 | 279.4 | 25.4 | 7.5 | 10.6 | 11.3 |
| 8 | 200 | 342.9 | 28.4 | 12.1 | 17.6 | 19.6 |
| 10 | 250 | 406.4 | 30.2 | 16.5 | 24 | 28.6 |
| 12 | 300 | 482.6 | 31.8 | 26.2 | 36.5 | 43.2 |
| 14 | 350 | 533.4 | 35.1 | 34.6 | 48.4 | 58.1 |
| 16 | 400 | 596.9 | 36.6 | 44.8 | 60.6 | 76.1 |
| 18 | 450 | 635 | 39.6 | 48.9 | 68.3 | 93.7 |
| 20 | 500 | 698.5 | 42.9 | 61.9 | 84.5 | 122.0 |
| 24 | 600 | 812.8 | 47.8 | 86.9 | 115 | 185.0 |
|
ASME B16.47 Flange Temperature |
||||||||
|
Flanges Tables |
-10° |
250° |
300° |
350° |
400° |
425° |
450° |
475° |
|
6 |
6 |
5.5 |
5 |
– |
– |
– |
– |
– |
|
10 |
10 |
9 |
8 |
7 |
6 |
– |
– |
– |
|
16 |
16 |
15 |
13 |
11 |
9 |
– |
– |
– |
|
25 |
25 |
24 |
21 |
17 |
14 |
12 |
9 |
6 |
|
40 |
40 |
38 |
33 |
28 |
23 |
20 |
15 |
10 |
|
64 |
64 |
61 |
53 |
44 |
36 |
32 |
24 |
16 |
|
100 |
100 |
95 |
83 |
70 |
57 |
50 |
37 |
25 |
|
160 |
160 |
152 |
132 |
112 |
92 |
80 |
60 |
40 |
